Špecifikácia:
Viac informácií uvádzame v priloženej dokumentácii
Bočný posuv ISO/FEM 3-4
Bočný posuv na VZV umožňuje rýchle a jednoduché presúvanie bremena o 100+100 mm (FEM 3) a 150+150 mm (FEM 4) do strán.
| Označenie | Nosnosť | Hmotnosť | ISO | Šírka zariadenia |
Min. šírka nosiča vidlíc |
| TRF 335.100P | 3500 kg/500 mm | 79 kg | 3 | 1000 mm | 900 mm |
| TRF 335.107P | 3500 kg/500 mm | 84 kg | 3 | 1070 mm | 950 mm |
| TRF 335.110P | 3500 kg/500 mm | 85 kg | 3 | 1100 mm | 1000 mm |
| TRF 335.115P | 3500 kg/500 mm | 88 kg | 3 | 1150 mm | 1000 mm |
| TRF 335.120P | 3500 kg/500 mm | 92 kg | 3 | 1200 mm | 1000 mm |
| TRF 335.125P | 3500 kg/500 mm | 93 kg | 3 | 1250 mm | 1100 mm |
| TRF 335.130P | 3500 kg/500 mm | 98 kg | 3 | 1300 mm | 1100 mm |
| TRF 335.135P | 3500 kg/500 mm | 103 kg | 3 | 1350 mm | 1100 mm |
| TRF 350.100P | 5000 kg/500 mm | 97 kg | 3 | 1000 mm | 900 mm |
| TRF 350.107P | 5000 kg/500 mm | 102 kg | 3 | 1070 mm | 950 mm |
| TRF 350.110P | 5000 kg/500 mm | 104 kg | 3 | 1100 mm | 950 mm |
| TRF 350.115P | 5000 kg/500 mm | 107 kg | 3 | 1150 mm | 950 mm |
| TRF 350.120P | 5000 kg/500 mm | 110 kg | 3 | 1200 mm | 1000 mm |
| TRF 350.126P | 5000 kg/500 mm | 115 kg | 3 | 1260 mm | 1000 mm |
| TRF 350.130P | 5000 kg/500 mm | 118 kg | 3 | 1300 mm | 1000 mm |
| TRF 350.135P | 5000 kg/500 mm | 120 kg | 3 | 1350 mm | 1050 mm |
| TRF 350.156P | 5000 kg/500 mm | 140 kg | 3 | 1560 mm | 1250 mm |
| TRF 350.166P | 5000 kg/500 mm | 145 kg | 3 | 1660 mm | 1350 mm |
| TRF 350.175P | 5000 kg/500 mm | 163 kg | 3 | 1750 mm | 1450 mm |
| TRF 350.185P | 5000 kg/500 mm | 170 kg | 3 | 1850 mm | 1500 mm |
| TRF 350.200P | 5000 kg/500 mm | 178 kg | 3 | 2000 mm | 1600 mm |
| TRF 465.120P | 6500 kg/600 mm | 193 kg | 4 | 1200 mm | 1050 mm |
| TRF 465.135P | 6500 kg/600 mm | 213 kg | 4 | 1350 mm | 1150 mm |
| TRF 465.160P | 6500 kg/600 mm | 258 kg | 4 | 1600 mm | 1300 mm |
| TRF 465.180P | 6500 kg/600 mm | 278 kg | 4 | 1800 mm | 1500 mm |
| TRF 480.180P | 8000 kg/600 mm | 310 kg | 4 | 1800 mm | 1500 mm |
| TRF 480.200P | 8000 kg/600 mm | 340 kg | 4 | 2000 mm | 1650 mm |
| TRF 480.220P | 8000 kg/600 mm | 368 kg | 4 | 2200 mm | 1850 mm |
| TRF 480.240P | 8000 kg/600 mm | 387 kg | 4 | 2400 mm | 1950 mm |
| TRF 4120.220P | 12000 kg/600 mm | 420 kg | 4 | 2200 mm | 1850 mm |
| TRF 4120.240R | 12000 kg/600 mm | 450 kg | 4 | 2400 mm | 1950 mm |
Výrobca: CAM system
Dokumentácia: PDF
Dostupnosť: skladom
