Integrovaný pozicionér s vidlicami na vodiacich tyčiach
Pozicionér vidlíc umožňuje nastavenie vzdialenosti medzi nosnými vidlicami, čo urýchľuje a zjednodušuje manipuláciu s bremenom na VZV.
Označenie | Nosnosť | Hmotnosť | Roztvorenie vidlíc | Šírka zariadenia |
Min. šírka nosiča vidlíc |
FPI 2.098 | 2500 kg/500 mm | 257 kg | 280/960 mm | 980 mm | 750 mm |
FPI 2.102 | 2500 kg/500 mm | 261 kg | 280/1020 mm | 1040 mm | 750 mm |
FPI 2.110 | 2500 kg/500 mm | 268 kg | 280/1080 mm | 1100 mm | 800 mm |
FPI 2.115 | 2500 kg/500 mm | 274 kg | 280/1130 mm | 1150 mm | 800 mm |
FPI 2.125 | 2500 kg/500 mm | 285 kg | 280/1230 mm | 1250 mm | 950 mm |
FPI 2.130 | 2500 kg/500 mm | 290 kg | 280/1280 mm | 1300 mm | 950 mm |
FPI 3.110 | 3500 kg/500 mm | 375 kg | 280/1060 mm | 1100 mm | 850 mm |
FPI 3.115 | 3500 kg/500 mm | 381 kg | 280/1110 mm | 1150 mm | 850 mm |
FPI 3.125 | 3500 kg/500 mm | 387 kg | 280/1210 mm | 1250 mm | 950 mm |
FPI 3.130 | 3500 kg/500 mm | 393 kg | 280/1260 mm | 1300 mm | 950 mm |
FPI 3.135 | 3500 kg/500 mm | 399 kg | 280/1310 mm | 1350 mm | 950 mm |
FPI 3.140 | 3500 kg/500 mm | 405 kg | 280/1360 mm | 1400 mm | 1000 mm |
FPI 3.145 | 3500 kg/500 mm | 411 kg | 280/1410 mm | 1450 mm | 1000 mm |
FPI 3.150 | 3500 kg/500 mm | 417 kg | 280/1460 mm | 1500 mm | 1000 mm |
FPI 5.110 | 4500 kg/600 mm | 570 kg | 340/1030 mm | 1100 mm | 850 mm |
FPI 5.115 | 4500 kg/600 mm | 579 kg | 340/1080 mm | 1150 mm | 850 mm |
FPI 5.125 | 4500 kg/600 mm | 595 kg | 340/1180 mm | 1250 mm | 950 mm |
FPI 5.135 | 4500 kg/600 mm | 610 kg | 340/1280 mm | 1350 mm | 950 mm |
FPI 5.150 | 4500 kg/600 mm | 638 kg | 340/1430 mm | 1500 mm | 1000 mm |
FPI 5.160 | 4500 kg/600 mm | 650 kg | 340/1530 mm | 1600 mm | 1000 mm |
FPI 6.160 | 6000 kg/600 mm | 910 kg | 390/1510 mm | 1600 mm | 1200 mm |
FPI 6.180 | 6000 kg/600 mm | 930 kg | 390/1610 mm | 1800 mm | 1400 mm |
FPI 6.200 | 6000 kg/600 mm | 950 kg | 390/1810 mm | 2000 mm | 1600 mm |
FPI 8.180 | 8000 kg/600 mm | 1090 kg | 410/1700 mm | 1800 mm | 1500 mm |
FPI 8.200 | 8000 kg/600 mm | 1125 kg | 410/1900 mm | 2000 mm | 1600 mm |
FPI 8.220 | 8000 kg/600 mm | 1160 kg | 410/2100 mm | 2200 mm | 1600 mm |
Dostupnosť: skladom
