Špecifikácia:
Viac informácií uvádzame v priloženej dokumentácii
Pridržiavač nákladu
Stabilizátor bremien zabezpečuje bezpečnú manipuláciu s nestabilným nákladom na VZV.
| Označenie | Hmotnosť | ISO 2328 | A | B |
Min. šírka nosiča vidlíc |
| SCA 100.0909 | 240 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 100.0910 | 245 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 100.1010 | 255 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 100.1012 | 280 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 100.1212 | 300 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 120.0909 | 335 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 120.0910 | 340 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 120.1010 | 350 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 120.1012 | 375 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 120.1212 | 395 kg | 2/3 | 1130/2110 mm | 1430 mm | 320 mm |
| SCA 130.0909 | 260 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 130.0910 | 307 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 130.1010 | 275 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 130.1012 | 300 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 130.1212 | 330 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 150.0909 | 355 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 150.0910 | 360 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 150.1010 | 370 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 150.1012 | 395 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
| SCA 150.1212 | 425 kg | 2/3 | 1400/2650 mm | 1700 mm | 320 mm |
Výrobca: CAM system
Dokumentácia: PDF
Dostupnosť: skladom
