Špecifikácia:
Viac informácií uvádzame v priloženej dokumentácii
Zvierajúce čeľuste otočné 360° s oddelenými ramenami - na papierové rolky
Zvierajúce otočné čeľuste na VZV Vám umožňujú jednoducho manipulovať s rolkami papiera.
| Označenie | Hmotnosť pri 360° | Nosnosť | ISO 2328 | B | C |
| CR 1665.S | 530 kg | 1600 kg/650 mm | 2/3 | 1190 mm | 705 mm |
| CR 1666.S | 530 kg | 1600 kg/650 mm | 2/3 | 1190 mm | 705 mm |
| CR 1680.S | 665 kg | 1600 kg/800 mm | 2/3 | 1190 mm | 850 mm |
| CR 1681.S | 665 kg | 1600 kg/800 mm | 2/3 | 1190 mm | 850 mm |
| CR 1865.S | 535 kg | 1800 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 1866.S | 535 kg | 1800 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 207.S | 670 kg | 2000 kg/700 mm | 3 | 900 mm | 850 mm |
| CR 2071.S | 670 kg | 2000 kg/700 mm | 3 | 900 mm | 850 mm |
| CR 2080.S | 770 kg | 2000 kg/800 mm | 3 | 1190 mm | 850 mm |
| CR 2081.S | 770 kg | 2000 kg/800 mm | 3 | 1190 mm | 850 mm |
| CR 2265.S | 590 kg | 2200 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 2266.S | 590 kg | 2200 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 2390.S | 930 kg | 2300 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 2391.S | 930 kg | 2300 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 25105.S | 1400 kg | 2500 kg/1050 mm | 4 | 1400 mm | 1050 mm |
| CR 2565.S | 705 kg | 2500 kg/650 mm | 3 | 900 mm | 850 mm |
| CR 2566.S | 705 kg | 2500 kg/650 mm | 3 | 900 mm | 850 mm |
| CR 2580.S | 940 kg | 2500 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 2581.S | 935 kg | 2500 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 2590.S | 970 kg | 2500 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 2591.S | 970 kg | 2500 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 2970.S | 1025 kg | 2700 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 2791.S | 1020 kg | 2700 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 2880.S | 965 kg | 2800 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 2881.S | 960 kg | 2800 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 3065.S | 765 kg | 3000 kg/650 mm | 3/4 | 900 mm | 934 mm |
| CR 3066.S | 765 kg | 3000 kg/650 mm | 3/4 | 900 mm | 934 mm |
| CR 3070.S | 770 kg | 3000 kg/700 mm | 3/4 | 900 mm | 934 mm |
| CR 3071.S | 770 kg | 3000 kg/700 mm | 3/4 | 900 mm | 934 mm |
| CR 3075.S | 795 kg | 3000 kg/750 mm | 3/4 | 900 mm | 934 mm |
| CR 3076.S | 795 kg | 3000 kg/750 mm | 3/4 | 900 mm | 934 mm |
| CR 3090.S | 1075 kg | 3000 kg/900 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3091.S | 1075 kg | 3000 kg/900 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3280.S | 1075 kg | 3200 kg/800 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3281.S | 1075 kg | 3200 kg/800 mm | 3/4 | 1100 mm | 1041 mm |
| CR 33100.S | 1350 kg | 3300 kg/1100 mm | 4 | 1400 mm | 1050 mm |
| CR 3370.S | 965 kg | 3300 kg/700 mm | 3/4 | 1050 mm | 1041 mm |
| CR 3371.S | 965 kg | 3300 kg/700 mm | 3/4 | 1050 mm | 1041 mm |
| CR 3375.S | 1065 kg | 3300 kg/750 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3376.S | 1065 kg | 3300 kg/750 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3490.S | 1320 kg | 3400 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 3491.S | 1310 kg | 3400 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 3565.S | 1050 kg | 3500 kg/650 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3566.S | 1050 kg | 3500 kg/650 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3580.S | 1296 kg | 3500 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 3581.S | 1296 kg | 3500 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 3890.S | 1335 kg | 3800 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 4080.S | 1290 kg | 4000 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 4081.S | 1290 kg | 4000 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 4275.S | 1275 kg | 4200 kg/750 mm | 4 | 1100 mm | 1041 mm |
| CR 4276.S | 1275 kg | 4200 kg/750 mm | 4 | 1100 mm | 1041 mm |
| CR 4565.S | 1275 kg | 4500 kg/650 mm | 4 | 1100 mm | 1041 mm |
| CR 4566.S | 1275 kg | 4500 kg/650 mm | 4 | 1100 mm | 1041 mm |
Výrobca: CAM system
Dokumentácia: PDF
Dostupnosť: skladom
