Zvierajúce čeľuste - na balíky

Špecifikácia:

Viac informácií uvádzame v priloženej dokumentácii

Všetky značky / Prídavné zariadenia a príslušenstvo / Pre vysokozdvižné vozíky / Zvierajúce zariadenia / Zvierajúce čeľuste - na balíky

Zvierajúce čeľuste - na balíky

Zvierajúce čeľuste umožňujú prepravu lisovaných materiálov (recyklovaný papier, recyklované plastové výrobky, textilné výrobky) pomocou VZV.

Označenie Hmotnosť Nosnosť ISO 2328 A B C
HB 10-A0T-09 369 kg 1000 kg/500 mm 2 450/1590 mm 950 mm 750 mm
HB 10-A0T-10 389 kg 1000 kg/500 mm 2 450/1590 mm 950 mm 750 mm
HB 10-A1T-09 375 kg 1000 kg/500 mm 2 550/1790 mm 950 mm 750 mm
HB 10-A1T-10 394 kg 1000 kg/500 mm 2 550/1790 mm 950 mm 750 mm
HB 14-A0T-09 382 kg 1400 kg/500 mm 2 550/1790 mm 950 mm 750 mm
HB 14-A0T-10 402 kg 1400 kg/500 mm 2 550/1790 mm 950 mm 750 mm
HB 14-B0T-09 387 kg 1400 kg/500 mm 2 450/1690 mm 1050 mm 750 mm
HB 14-B0T-10 412 kg 1400 kg/500 mm 2 450/1690 mm 1050 mm 750 mm
HB 14-C0T-09 402 kg 1400 kg/500 mm 2 450/1790 mm 1150 mm 750 mm
HB 14-C0T-10 392 kg 1400 kg/500 mm 2 450/1790 mm 1150 mm 750 mm
HB 14-C1T-09 412 kg 1400 kg/500 mm 2 650/2190 mm 1150 mm 750 mm
HB 14-C1T-10 432 kg 1400 kg/500 mm 2 650/2190 mm 1150 mm 750 mm
HB 18-A0T-10 448 kg 1800 kg/500 mm 2 560/1780 mm 950 mm 750 mm
HB 18-A0T-12 460 kg 1800 kg/500 mm 2 560/1780 mm 950 mm 750 mm
HB 18-B0T-10 446 kg 1800 kg/500 mm 2 460/1680 mm 1050 mm 750 mm
HB 18-B0T-12 461 kg 1800 kg/500 mm 2 460/1680 mm 1050 mm 750 mm
HB 18-C0T-10 453 kg 1800 kg/500 mm 2 560/1980 mm 1150 mm 750 mm
HB 18-C0T-12 485 kg 1800 kg/500 mm 2 560/1980 mm 1150 mm 750 mm
HB 18-D0T-10 468 kg 1800 kg/500 mm 2 460/1880 mm 1250 mm 850 mm
HB 18-D0T-12 494 kg 1800 kg/500 mm 2 460/1880 mm 1250 mm 850 mm
HB 22-A0T-10 492 kg 2200 kg/500 mm 2 570/1800 mm 950 mm 750 mm
HB 22-A0T-12 460 kg 2200 kg/500 mm 2 570/1800 mm 950 mm 750 mm
HB 22-B0T-10 457 kg 2200 kg/500 mm 2 660/2080 mm 1050 mm 750 mm
HB 22-B0T-12 485 kg 2200 kg/500 mm 2 660/2080 mm 1050 mm 750 mm
HB 22-C0T-10 469 kg 2200 kg/500 mm 2 560/1980 mm 1150 mm 750 mm
HB 22-C0T-12 494 kg 2200 kg/500 mm 2 560/1980 mm 1150 mm 750 mm
HB 22-D0T-10 480 kg 2200 kg/500 mm 2 570/2100 mm 1250 mm 850 mm
HB 22-D0T-12 508 kg 2200 kg/500 mm 2 570/2100 mm 1250 mm 850 mm
HB 26-A0T-10 470 kg 2600 kg/500 mm 2/3 550/1860 mm 1050 mm 750 mm
HB 26-A0T-12 492 kg 2600 kg/500 mm 2/3 550/1860 mm 1050 mm 750 mm
HB 26-B0T-10 484 kg 2600 kg/500 mm 2/3 670/2200 mm 1150 mm 750 mm
HB 26-B0T-12 509 kg 2600 kg/500 mm 2/3 670/2200 mm 1150 mm 750 mm
HB 26-C0T-10 497 kg 2600 kg/500 mm 2/3 530/2020 mm 1250 mm 850 mm
HB 26-C0T-12 522 kg 2600 kg/500 mm 2/3 530/2020 mm 1250 mm 850 mm
HB 26-D0T-10 505 kg 2600 kg/500 mm 2/3 670/2320 mm 1320 mm 850 mm
HB 26-D0T-12 530 kg 2600 kg/500 mm 2/3 670/2320 mm 1320 mm 850 mm
HB 30-A0T-12 824 kg 3000 kg/500 mm 3 630/2090 mm 1150 mm 850 mm
HB 30-A0T-14 849 kg 3000 kg/500 mm 3 630/2090 mm 1150 mm 850 mm
HB 30-B0T-12 837 kg 3000 kg/500 mm 3 520/1990 mm 1250 mm 850 mm
HB 30-B0T-14 867 kg 3000 kg/500 mm 3 520/1990 mm 1250 mm 850 mm
HB 30-C0T-12 852 kg 3000 kg/500 mm 3 640/2300 mm 1320 mm 850 mm
HB 30-C0T-14 883 kg 3000 kg/500 mm 3 640/2300 mm 1320 mm 850 mm
HB 35-A0T-12 819 kg 3500 kg/500 mm 3 430/1730 mm 1150 mm 900 mm
HB 35-A0T-14 844 kg 3500 kg/500 mm 3 430/1730 mm 1150 mm 900 mm
HB 35-B0T-12 829 kg 3500 kg/500 mm 3 690/2420 mm 1320 mm 1000 mm
HB 35-B0T-14 861 kg 3500 kg/500 mm 3 690/2420 mm 1320 mm 1000 mm
HB 35-C0T-12 846 kg 3500 kg/500 mm 3 560/2290 mm 1450 mm 1000 mm
HB 35-C0T-14 874 kg 3500 kg/500 mm 3 560/2290 mm 1450 mm 1000 mm
HB 42-A0T-12 931 kg 4200 kg/500 mm 3 600/2070 mm 1150 mm 900 mm
HB 42-A0T-14 965 kg 4200 kg/500 mm 3 600/2070 mm 1150 mm 900 mm
HB 42-A0T-16 992 kg 4200 kg/500 mm 3 600/2070 mm 1150 mm 900 mm
HB 42-B0T-12 959 kg 4200 kg/500 mm 3 560/2160 mm 1320 mm 1000 mm
HB 42-B0T-14 987 kg 4200 kg/500 mm 3 560/2160 mm 1320 mm 1000 mm
HB 42-B0T-16 1016 kg 4200 kg/500 mm 3 560/2160 mm 1320 mm 1000 mm
HB 42-C0T-12 990 kg 4200 kg/500 mm 3 680/2500 mm 1450 mm 1050 mm
HB 42-C0T-14 1023 kg 4200 kg/500 mm 3 680/2500 mm 1450 mm 1050 mm
HB 42-C0T-16 1059 kg 4200 kg/500 mm 3 680/2500 mm 1450 mm 1050 mm
HB 45-A0T-12 1030 kg 4500 kg/600 mm 4 600/2320 mm 1450 mm 1050 mm
HB 45-A0T-14 1069 kg 4500 kg/600 mm 4 600/2320 mm 1450 mm 1050 mm
HB 45-A0T-16 1100 kg 4500 kg/600 mm 4 600/2320 mm 1450 mm 1050 mm
HB 45-B0T-12 1052 kg 4500 kg/600 mm 4 700/2670 mm 1600 mm 1050 mm
HB 45-B0T-14 1088 kg 4500 kg/600 mm 4 700/2670 mm 1600 mm 1050 mm
HB 45-B0T-16 1129 kg 4500 kg/600 mm 4 700/2670 mm 1600 mm 1050 mm
HB 60-A0T-14 1295 kg 6000 kg/600 mm 4 630/2510 mm 1600 mm 1050 mm
HB 60-A0T-16 1360 kg 6000 kg/600 mm 4 630/2510 mm 1600 mm 1050 mm
HB 60-B0T-14 1330 kg 6000 kg/600 mm 4 710/2870 mm 1800 mm 1050 mm
HB 60-B0T-16 1395 kg 6000 kg/600 mm 4 710/2870 mm 1800 mm 1050 mm
HB 80-A0T-16 2800 kg 8000 kg/800 mm 4 650/3300 mm 2500 mm

Výrobca: CAM system

Dokumentácia: PDF

Dostupnosť: skladom

Kontaktujte nás pre viac info o tomto tovare
