Špecifikácia:
Viac informácií uvádzame v priloženej dokumentácii
Zvierajúce čeľuste otočné 360° - na papierové rolky
Zvierajúce otočné čeľuste na VZV Vám umožňujú jednoducho manipulovať s rolkami papiera.
| Označenie |
Hmotnosť pri 360° |
Nosnosť | ISO 2328 | B | C |
| CR 10105 | 830 kg | 1000 kg/1050 mm | 3 | 1300 mm | 680 mm |
| CR 1050 | 390 kg | 1000 kg/500 mm | 2 | 990 mm | 330 mm |
| CR 1265 | 525 kg | 1200 kg/650 mm | 2 | 1190 mm | 675 mm |
| CR 1266 | 530 kg | 1200 kg/650 mm | 2 | 1190 mm | 675 mm |
| CR 1276 | 550 kg | 1200 kg/750 mm | 2 | 1190 mm | 675 mm |
| CR 1281 | 680 kg | 1200 kg/800 mm | 2 | 1190 mm | 675 mm |
| CR 1355 | 545 kg | 1300 kg/550 mm | 2 | 890 mm | 690 mm |
| CR 1655 | 560 kg | 1600 kg/550 mm | 2 | 890 mm | 690 mm |
| CR 1656 | 560 kg | 1600 kg/550 mm | 2 | 890 mm | 690 mm |
| CR 1665 | 630 kg | 1600 kg/650 mm | 2 | 1190 mm | 705 mm |
| CR 1666 | 630 kg | 1600 kg/650 mm | 2 | 1190 mm | 705 mm |
| CR 1680 | 696 kg | 1600 kg/800 mm | 2/3 | 1190 mm | 850 mm |
| CR 1681 | 705 kg | 1600 kg/800 mm | 2/3 | 1190 mm | 850 mm |
| CR 1865 | 635 kg | 1800 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 1866 | 635 kg | 1800 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 2070 | 670 kg | 2000 kg/700 mm | 3 | 900 mm | 850 mm |
| CR 2071 | 670 kg | 2000 kg/700 mm | 3 | 900 mm | 850 mm |
| CR 2080 | 737 kg | 2000 kg/800 mm | 3 | 1190 mm | 850 mm |
| CR 2081 | 737 kg | 2000 kg/800 mm | 3 | 1190 mm | 850 mm |
| CR 2265 | 640 kg | 2200 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 2266 | 640 kg | 2200 kg/650 mm | 2 | 900 mm | 850 mm |
| CR 2390 | 930 kg | 2300 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 2391 | 930 kg | 2300 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 25105 | 1400 kg | 2500 kg/1050 mm | 4 | 1400 mm | 1050 mm |
| CR 2565 | 748 kg | 2500 kg/650 mm | 3 | 900 mm | 850 mm |
| CR 2566 | 733 kg | 2500 kg/650 mm | 3 | 900 mm | 850 mm |
| CR 2580 | 945 kg | 2500 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 2581 | 940 kg | 2500 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 2590 | 1085 kg | 2500 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 2591 | 1070 kg | 2500 kg/900 mm | 3/4 | 1100 mm | 934 mm |
| CR 2790 | 1030 kg | 2700 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 2791 | 1025 kg | 2700 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 2880 | 970 kg | 2800 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 2881 | 935 kg | 2800 kg/800 mm | 3/4 | 900 mm | 934 mm |
| CR 3065 | 765 kg | 3000 kg/650 mm | 3/4 | 900 mm | 934 mm |
| CR 3066 | 765 kg | 3000 kg/650 mm | 3/4 | 900 mm | 934 mm |
| CR 3070 | 770 kg | 3000 kg/700 mm | 3/4 | 900 mm | 934 mm |
| CR 3071 | 770 kg | 3000 kg/700 mm | 3/4 | 900 mm | 934 mm |
| CR 3075 | 795 kg | 3000 kg/750 mm | 3/4 | 900 mm | 934 mm |
| CR 3076 | 795 kg | 3000 kg/750 mm | 3/4 | 900 mm | 934 mm |
| CR 3090 | 1075 kg | 3000 kg/900 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3091 | 1075 kg | 3000 kg/900 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3280 | 1075 kg | 3200 kg/800 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3281 | 1075 kg | 3200 kg/800 mm | 3/4 | 1100 mm | 1041 mm |
| CR 33100 | 1350 kg | 3300 kg/1100 mm | 4 | 1400 mm | 1050 mm |
| CR 3370 | 965 kg | 3300 kg/700 mm | 3/4 | 1050 mm | 1041 mm |
| CR 3371 | 965 kg | 3300 kg/700 mm | 3/4 | 1050 mm | 1041 mm |
| CR 3375 | 1065 kg | 3300 kg/750 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3376 | 1065 kg | 3300 kg/750 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3490 | 1315 kg | 3400 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 3491 | 1305 kg | 3400 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 3565 | 1050 kg | 3500 kg/650 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3566 | 1050 kg | 3500 kg/650 mm | 3/4 | 1100 mm | 1041 mm |
| CR 3580 | 1296 kg | 3500 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 3581 | 1296 kg | 3500 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 3890 | 1335 kg | 3800 kg/900 mm | 4 | 1100 mm | 1041 mm |
| CR 4080 | 1290 kg | 4000 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 4081 | 1290 kg | 4000 kg/800 mm | 4 | 1100 mm | 1041 mm |
| CR 4275 | 1275 kg | 4200 kg/750 mm | 4 | 1100 mm | 1041 mm |
| CR 4276 | 1275 kg | 4200 kg/750 mm | 4 | 1100 mm | 1041 mm |
| CR 4565 | 1275 kg | 4500 kg/650 mm | 4 | 1100 mm | 1041 mm |
| CR 4566 | 1275 kg | 4500 kg/650 mm | 4 | 1100 mm | 1041 mm |
Výrobca: CAM system
Dokumentácia: PDF
Dostupnosť: skladom
